Our PS charger utililizes our patented "3 Stage Plus" technology to interact with the battery
            and provide exactly the right amount of charge. Interacter "3 Stage Plus" charging technology
            eliminates undercharging, overcharging, or damage to the battery, and is completely safe.
            The Interacter PS can be used to recharge virtually any type lead-acid battery including
            conventional liquid electrolyte, maintenance-free absorbed electrolyte, deep-cycle,
            and gelled type batteries.



        Interacter's microprocessor circuitry with patented program in EPROM, controls four separate charging stages:

     FIRST: A constant current bulk charge is applied to achieve the fastest possible return of energy to the battery.

SECOND: This constant voltage stage is proportionally timed and temperature compensated, minimizing electrolyte breakdown
                   and gas emission.

   THIRD: The final standby float charge stage will replace standing losses and keep the battery in a fully charged state & "Ready".

      PLUS: As soon as the battery is connected, a de-sulfation circuit encourages the breakdown of large sulfate crystals which can
                  develop during prolonged periods of deep discharge.




External Temperature Compensation Electronic Current Limit Protection Unique De-sulfation Circuit Short Circuit Shutdown Phase Angle Control Voltage Limited Provides DC Power While Charging

Digital Microprocessor Control Compact Size Three Stage Plus Control Safety Override Timer Green ready Lamp / Fault indicator Timed C.V. Stage / 80% Returned

Customer Preferred LED Amp Meter Low Voltage Start Powder Coated Finish Modular Construction Fully Automatic Operation Proportional Timing Battery Type Switch




Built-In Additional Features:

• A low voltage start circuit which will recharge over-discharged batteries from as low as 400 millivolts.
• Incorporated in the PS is a sample and hold circuit which eliminates voltage sensing errors and prevents parasitic discharge
  during AC power loss.
• Electronic short circuit and reverse polarity shutdown, without blowing fuses, an exceptional safety feature.
• The built in electronic timer monitors the time taken from start of charge until the battery voltage reaches the first preset voltage limit.
  The time duration for the second stage is automatically calculated in proportion to the time taken for the first stage. This feature is
  specifically designed to optimize charging on a wide range of battery types, ages and sizes.
• A customer preferred LED Amp gauge indicates the current output without fragile moving meters or energy loss. A green ready
  indicator shows positively that the battery is ready for use or will flash if there is an override timeout.

PS Series Specifications
